PERSONAL WORN SCAVENGER™ (PWS)
Provides compact power scavenging capability to mobile operators
-
Wearable power & data
FEATURES
THE NERV CENTR PERSONAL-WORN SCAVENGER™ (PWS) can scavenge power from solar, vehicle, AC or Nett Warrior batteries. The compact plug-and-play component integrates with the soldier-wearable power and data system for power sustainment while on the move.
Key Features
Specifications
Designed to fit within one MOLLE channel, the PWS eliminates the need for individual device batteries by providing power management through a singular port.
CONNECTORS: Nett Warrior 6-pin
INPUT: SAE Connector
COMMUNICATION: SMBus v1.1 & 2.0
POWER: 60W peak; 40W continuous
INPUT VOLTAGE: 7V - 40V
OUTPUT VOLTAGE: 10V - 20 VDC
MAX CURRENT: 5A
OPERATING TEMPERATURE:
-4°F (-20°C) to 149°F (65°C)
Weight
OS |
|
oz |
3.2 |
g |
91 |
